Pioneer DEH-X6500BT Service Manual

DEH-X65BT/XNUC
37
5 678
56
7
8
C
D
F
A
B
E
(1) PACKING SECTION PARTS LIST
(2) CONTRAST TABLE
DEH-X65BT/XNUC, DEH-X6500BT/XNUC, DEH-X5500BT/XNEW5, DEH-X6550BT/XNES and DEH-X6590BT/
XNID are constructed the same except for the following:
Owner's Manual,Installation Manual
Mark No. Description Part No.
1 Cord Assy See Contrast table (2)
2 Polyethylene Bag See Contrast table (2)
3 Protector See Contrast table (2)
4 Protector See Contrast table (2)
5 Protector See Contrast table (2)
6 Microphone Assy CPM1083
7 Holder CZN7192
8 Cushion CZN7193
9 Screw See Contrast table (2)
10 Polyethylene Bag See Contrast table (2)
11 Screw See Contrast table (2)
12 Handle QNC3021
13 Screw See Contrast table (2)
14 Unit Box See Contrast table (2)
15 Contain Box See Contrast table (2)
16 Case Assy See Contrast table (2)
17 IM CD ROM See Contrast table (2)
18 Card Remote Control Unit See Contrast table (2)
19-1 Owner's Manual See Contrast table (2)
* 19-2 Warranty Card See Contrast table (2)
19-3 Quick Start Guide See Contrast table (2)
19-4 Installation Manual See Contrast table (2)
* 19-5 Caution Card See Contrast table (2)
* 19-6 Caution Card See Contrast table (2)
* 19-7 Caution Card See Contrast table (2)
* 19-8 Service Network See Contrast table (2)
Mark
No. Description Part No.
Mark No. Description
DEH-X65BT/
XNUC
DEH-X6500BT/
XNUC
DEH-X5500BT/
XNEW5
DEH-X6550BT/
XNES
DEH-X6590BT/
XNID
1 Cord Assy CDP1480 CDP1480 QDP3014 CDP1480 CDP1480
2 Polyethylene Bag CEG1173 CEG1173 QEG3001 QEG3001 QEG3001
3 Protector CHP4103 Not used Not used Not used Not used
4 Protector CHP4104 Not used Not used Not used Not used
5 Protector Not used CHP4594 CHP4594 CHP4594 CHP4594
9 Screw BPZ20P060FTC BPZ20P060FTC Not used Not used Not used
10 Polyethylene Bag CEG1160 CEG1160 Not used CEG1160 CEG1160
11 Screw CRZ50P090FTC CRZ50P090FTC Not used Not used Not used
13 Screw TRZ50P080FTC TRZ50P080FTC Not used TRZ50P080FTC TRZ50P080FTC
14 Unit Box QHG3361 QHG3360 QHG3359 QHG3362 QHG3363
15 Contain Box QHL3361 QHL3360 QHL3359 QHL3362 QHL3363
16 Case Assy Not used Not used QXA3129 QXA3129 QXA3129
17 IM CD ROM Not used Not used QPJ3013 Not used Not used
18
Card Remote Control Unit QXE1044 QXE1044 Not used QXE1044 QXE1044
19-1 Owner's Manual QRD3123 QRD3123 Not used QRD3124 QRB3246
* 19-2 Warranty Card QRY3001 QRY3001 CRY1376 Not used CRY1304
19-3 Quick Start Guide Not used Not used QRD3140 Not used Not used
19-4 Installation Manual Not used Not used QRD3141 Not used Not used
* 19-5 Caution Card Not used Not used QRP3014 Not used Not used
* 19-6 Caution Card Not used Not used CRP1438 Not used Not used
* 19-7 Caution Card Not used Not used CRP1441 Not used Not used
* 19-8 Service Network Not used Not used Not used Not used CRY1305
Part No. Language
QRD3123 English, French, Spanish(Espanol)
QRD3124
English, Spanish(Espanol), Portuguese(B), Traditional Chinese, Arabic, Persian
QRD3140 English, French, Italian, Spanish(Espanol), German, Dutch, Russian
QRD3141 English, French, Italian, Spanish(Espanol), German, Dutch, Russian
QRB3246 English

Pioneer DEH-X6500BT Specifications

General

MP3 playback	Yes
Preset stations quantity	24
Product color	Black
Volume control	Rotary
Disc types supported	CD, CD-R, CD-RW
Equalizer bands quantity	5
Display type	LCD
Display number of colors	210000 colors
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HFP, SSP
Line outputs (RCA)	2
USB ports quantity	1
Handheld remote control	No
Amplifier output power	200 W
