Pioneer DEH-X6500BT Service Manual

DEH-X65BT/XNUC
41
5 678
56
7
8
C
D
F
A
B
E
(1) EXTERIOR SECTION PARTS LIST
(2) CONTRAST TABLE
DEH-X65BT/XNUC, DEH-X6500BT/XNUC, DEH-X5500BT/XNEW5, DEH-X6550BT/XNES and DEH-X6590BT/
XNID are constructed the same except for the following:
Mark No. Description Part No.
1 Screw ASZ26P050FTC
2 Screw BSZ26P060FTC
3 Screw BSZ26P080FTC
4 Screw BSZ26P120FTC
5 Cord Assy See Contrast table (2)
6 CD Mechanism Module (S11.6) CXK5804
7 FFC QDE3029
8 Case QNB3006
9 Holder QNC3020
10 Panel QNS3417
11 Tuner Amp Unit See Contrast table (2)
12 Screw BPZ26P080FTC
13 Screw BSZ26P060FTC
14 Screw BSZ26P120FTC
15 Holder QNC3053
16 Heat Sink See Contrast table (2)
> 17 Fuse (10 A) YEK5001
18 Spring QBH3001
19 Cover QNM3029
20 Panel QNS3416
21 Arm QNV3025
22 Button QNV3026
23 Detachable Grille Assy See Contrast table (2)
24 Screw BPZ20P100FTC
25 Spring CBH2210
26 Knob Unit CXE3692
27 Spring YBL5010
28 Button (EJECT) QAC3084
29 Button (1-6) QAC3085
30 Button (DETACH) QAC3087
31 Door QAT3007
32 •••••
33 Sheet QNM3060
34 Cover QNS3415
35 Lighting Conductor QNV3057
36 Lighting Conductor QNV3058
37 Segment LCD (V1802) CAW2025
38 Holder QNC3047
39 Rubber Connector QNV3053
40 Lighting Conductor QNV3054
41 Grille Unit See Contrast table (2)
42 Card Remote Control Unit See Contrast table (2)
43 Cover See Contrast table (2)
44 Label See Contrast table (2)
45 FFC QDE3028
46 BT Unit QWM3533
47 BT Module CWX4294
* 48 Seal See Contrast table (2)
Mark
No. Description Part No.
Mark No. Description
DEH-X65BT/
XNUC
DEH-X6500BT/
XNUC
DEH-X5500BT/
XNEW5
DEH-X6550BT/
XNES
DEH-X6590BT/
XNID
5 Cord Assy CDP1480 CDP1480 QDP3014 CDP1480 CDP1480
11 Tuner Amp Unit QWM3432 QWM3431 QWM3430 QWM3433 QWM3434
16 Heat Sink QNR3010 QNR3010 QNR3010 QNR3002 QNR3002
23 Detachable Grille
Assy
QXA3701 QXA3700 QXA3699 QXA3702 QXA3703
41 Grille Unit QXA3676 QXA3675 QXA3674 QXA3677 QXA3678
42 Card Remote Con-
trol Unit
QXE1044 QXE1044 Not used QXE1044 QXE1044
43 Cover CNS7068 CNS7068 Not used CNS7068 CNS7068
44 Label Not used Not used Not used Not used CNN3533
* 48 Seal CAN3984 Not used Not used Not used Not used

Pioneer DEH-X6500BT Specifications

General

MP3 playback	Yes
Preset stations quantity	24
Product color	Black
Volume control	Rotary
Disc types supported	CD, CD-R, CD-RW
Equalizer bands quantity	5
Display type	LCD
Display number of colors	210000 colors
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HFP, SSP
Line outputs (RCA)	2
USB ports quantity	1
Handheld remote control	No
Amplifier output power	200 W
