DEH-X65BT/XNUC
71
C 901 (A,133,124) 2 200 uF/16 V CCH2040
C 912 (A,152,40) CKSSYB102K50
C 913 (A,131,43) CKSSYB102K50
C 914 (A,156,56) 1 000 uF/16 V CCH2024
C 915 (A,132,42) CKSRYB104K16
C 916 (A,146,43) 4.7 uF CCG1201
C 917 (A,145,46) CKSSYB102K50
C 919 (A,151,42) 4.7 uF CCG1201
C 921 (A,135,42) 4.7 uF CCG1201
C 923 (A,159,41) 4.7 uF CCG1201
C 926 (A,140,44) 4.7 uF CCG1201
C 927 (A,139,42) CKSSYB102K50
C 941 (A,96,124) CKSRYB104K16
C 961 (A,126,107) CKSSYB104K16
C 962 (A,132,107) CKSSYB104K16
C 966 (A,128,112) CKSSYB333K16
C 969 (A,135,113) 22 uF DCH1256
C 973 (A,98,53) CCSSCH470J50
B
Unit Number :
Unit Name : Keyboard Unit
MISCELLANEOUS
IC 1802 (B,84,22) IC PDC202B
IC 1851 (B,47,20) IC BH2228FV
IC 1941 (A,149,40) Remote IC GP1UXC14RK
Q 1851 (B,40,12) Transistor LSCR523UB
Q 1852 (B,32,9) Transistor LSCR523UB
Q 1853 (B,35,10) Transistor LSCR523UB
Q 1854 (B,57,16) Transistor LSCR523UB
Q 1855 (B,58,18) Transistor LSCR523UB
Q 1856 (B,57,23) Transistor LSCR523UB
Q 1857 (B,22,12) Transistor LSCR523UB
Q 1858 (B,15,12) Transistor LSCR523UB
Q 1859 (B,12,28) Transistor LSCR523UB
Q 1866 (B,105,24) Transistor LSCR523UB
Q 1867 (B,112,25) Transistor LSCR523UB
Q 1868 (B,119,25) Transistor LSCR523UB
D 1882 (A,10,22) LED SMLVN6RGB2U(A)
D 1883 (A,40,22) LED SMLVN6RGB2U(A)
D 1884 (A,164,22) LED SMLVN6RGB2U(A)
D 1885 (A,48,23) LED MSL0101RGBU
D 1886 (A,147,24) LED MSL0101RGBU
L 1802 (B,136,11) Inductor CTF1389
L 1803 (B,131,6) Inductor CTF1389
L 1804 (B,135,5) Inductor CTF1389
X 1801 (B,69,22)
Ceramic Resonator 5.00 MHz
CSS1547
S 1821 (A,53,5) Push Switch CSG1155
S 1822 (A,9,41) Push Switch CSG1155
S 1823 (A,64,5) Push Switch CSG1155
S 1824 (A,11,6) Push Switch CSG1155
S 1826 (A,6,22) Push Switch CSG1155
S 1828 (A,39,34) Push Switch CSG1155
S 1830
(A,25,22)Encoder(MULTI-CONTROL) CSD1168
S 1832 (A,39,10) Push Switch CSG1155
S 1834 (A,137,5) Push Switch CSG1155
S 1835 (A,127,5) Push Switch CSG1155
S 1836 (A,106,5) Push Switch CSG1155
Circuit Symbol and No. Part No.
S 1837 (A,116,5) Push Switch CSG1155
S 1838 (A,85,5) Push Switch CSG1155
S 1839 (A,95,5) Push Switch CSG1155
S 1840 (A,74,5) Push Switch CSG1155
S 1842 (A,10,36) Push Switch CSG1155
CN1911 (A,157,26) Connector CKS6443
CN1931 (B,109,10) Connector CKS6451
JA1921 (A,154,12) Jack CKN1094
V 1802 (A,53,33) Segment LCD CAW2025
RESISTORS
R 1809 (B,75,14) RS1/16SS473J
R 1810 (B,63,21) RS1/16SS103J
R 1824 (B,33,30) RS1/16SS273J
R 1851 (B,50,15) RS1/10SR222J
R 1852 (B,48,15) RS1/10SR222J
R 1853 (B,47,15) RS1/10SR222J
R 1854 (B,41,15) RS1/16SS102J
R 1856 (B,41,18) RS1/16SS102J
R 1858 (B,42,20) RS1/16SS102J
R 1860 (B,53,19) RS1/16SS102J
R 1862 (B,55,19) RS1/16SS102J
R 1864 (B,54,22) RS1/16SS102J
R 1866 (B,29,11) RS1/16SS101J
R 1867 (B,21,14) RS1/16SS101J
R 1868 (B,12,30) RS1/16SS101J
R 1875 (B,58,14) RS1/16SS101J
R 1876 (B,57,20) RS1/16SS101J
R 1877 (B,54,24) RS1/16SS101J
R 1881 (B,27,10) RS1/16SS680J
R 1882 (B,28,9) RS1/16SS0R0J
R 1883 (B,18,11) RS1/16SS680J
R 1884 (B,19,11) RS1/16SS0R0J
R 1885 (B,13,25) RS1/16SS680J
R 1886 (B,14,23) RS1/16SS0R0J
R 1899 (B,107,27) RS1/16SS680J
R 1900 (B,108,28) RS1/16SS0R0J
R 1901 (B,113,28) RS1/16SS680J
R 1902 (B,115,28) RS1/16SS0R0J
R 1903 (B,118,28) RS1/16SS680J
R 1904 (B,118,29) RS1/16SS0R0J
R 1931 (B,89,7) RS1/10SR222J
R 1932 (B,91,8) RS1/10SR222J
R 1944 (B,144,28) RS1/10SR101J
CAPACITORS
C 1801 (B,78,12) CKSSYB104K10
C 1802 (B,77,12) CKSSYB104K10
C 1803 (B,79,12) CKSSYB104K10
C 1804 (B,72,22) CKSRYB105K10
C 1805 (B,72,24) CKSSYB104K10
C 1851 (B,52,13) CCSRCH100D50
C 1852 (B,51,15) CCSRCH100D50
C 1853 (B,45,15) CCSRCH100D50
C 1854 (B,52,23) CKSSYB103K16
C 1855 (B,52,24) CKSRYB105K10
C 1911 (B,146,27) CKSRYB104K16
C 1912 (B,149,18) CKSRYB104K16
C 1941 (B,143,30) 10 uF CCG1192
Circuit Symbol and No. Part No.
