Pioneer GM-3500T/XZUC User Manual

GM-3500T/XZUC
6
1234
1234
C
D
F
A
B
E
2. SPECIFICATIONS
2.1 SPECIFICATIONS
Power source............................ 14.4 V DC (10.8 V to 15.1 V
allowable)
Grounding system.................. Negative type
Current consumption ............15 A (at continuous power,
4 Ω)
Average current drawn......... 4 A (4 Ω for two channels)
7 A (4 Ω for one channel)
Fuse ................................................25 A × 1
Dimensions (W × H × D) ...289 mm × 62 mm ×
219 mm
(11-3/8 in. × 2-1/2 in. ×
8-5/8 in.)
Weight ........................................ 2.0 kg (4.4 lbs)
(Leads for wiring not in-
cluded)
Maximum power output ....... 400 W (200 W × 2)
Continuous power output ...60 W × 2 (at 14.4 V, 4 Ω,
20 Hz to 20 kHz, 1.0 % THD
+N)
185 W × 1 (at 14.4 V, 4 Ω
BRIDGE 1 kHz, 1.0 % THD
+N)
85 W × 2 (at 14.4 V, 2 Ω,
1 kHz, 1.0 % THD+N)
Load impedance ..................... 4 Ω (2 Ω to 8 Ω allowable)
Frequency response...............10 Hz to 70 kHz (+0 dB,–
3 dB)
Signal-to-noise ratio.............. 98 dB (IHF-A network)
Distortion ................................... 0.05 % (10 W, 1 kHz)
Low pass filter:
Cut off frequency .......... 80 Hz
Cut off slope.................... –12 dB/oct
Gain control:
RCA .................................... 200 mV to 6.5 V
Speaker ............................ 0.8 V to 26 V
Maximum input level / impedance:
RCA .................................... 6.5 V / 22 kΩ
Speaker ............................ 26 V / 22 kΩ
CEA2006 Specifications
Power output ........................... 60 W RMS × 2 Channels (at
14.4 V, 4 Ω and 1 % THD
+N)
S/N ratio ..................................... 80 dBA (reference: 1 W into
4 Ω)
Notes
 Specifications and the design are subject to
modifications without notice.
 The average current drawn is nearly the maxi-
mum current drawn by this unit when an
audio signal is input. Use this value when
working out total current drawn by multiple
power amplifiers.
Power source............................ 14.4 V DC (10.8 V to 15.1 V
allowable)
Grounding system.................. Negative type
Current consumption ............15 A (at continuous power,
4 Ω)
Average current drawn........ 4 A (4 Ω for two channels)
7 A (4 Ω for one channel)
Fuse .............................................. 25 A × 1
Dimensions (W × H × D) ...289 mm × 62 mm × 219
mm
Weight ........................................ 2.0 kg (Leads for wiring not
included)
Maximum power output ....... 400 W (200 W × 2)
Continuous power output ...60 W × 2 (at 14.4 V, 4 Ω,
20 Hz to 20 kHz, 1.0 % THD
+N)
185 W × 1 (at 14.4 V, 4 Ω
BRIDGE 1 kHz, 1.0 % THD
+N)
85 W × 2 (at 14.4 V, 2 Ω,
1 kHz, 1.0 % THD+N)
Load impedance ..................... 4 Ω (2 Ω to 8 Ω allowable)
Frequency response...............10 Hz to 70 kHz (+0 dB,–
3 dB)
Signal-to-noise ratio.............. 98 dB (IEC-A network)
Distortion ................................... 0.05 % (10 W, 1 kHz)
Low pass filter:
Cut off frequency .......... 80 Hz
Cut off slope.................... –12 dB/oct
Gain control:
RCA .................................... 200 mV to 6.5 V
Speaker ............................ 0.8 V to 26 V
Maximum input level / impedance:
RCA .................................... 6.5 V / 22 kΩ
Speaker ............................ 26 V / 22 kΩ
Notes
 Specifications and the design are subject to
modifications without notice.
 The average current drawn is nearly the maxi-
mum current drawn by this unit when an
audio signal is input. Use this value when
working out total current drawn by multiple
power amplifiers.
• GM-3500T/XZUC • GM-3500T/XZEW5, XZES
Backup current ....................... 1 mA or less
Backup current ....................... 1 mA or less
<
=
<
=
<
=
<
=
<
=
<
=
<
=
