PDP-S38
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
OTES:
PARTS LIST
NSP Cabinet SNK2899
NSP Baffle R SNK2897
NSP Baffle L SNK2898
Grille ASSY SMG1854
NSP Grille Cloth SAS1598
NSP Felt SED1124
NSP Felt SED1125
NSP Grille Frame SMH1111
NSP Cosmetic Frame SNK2900
Network ASSY SWN1755
for XIN/E5 type
NSP Model Label (L) SAN3748
NSP Model Label (R) SAN3749
for XIN/CN type
NSP Model Label (L) SAN3744
NSP Model Label (R) SAN3745
NSP Insert Nut M5 SBN1056
NSP Packing (BOSS: WF TW) SEB1244
NSP Gasket (INP-SIDE) SEB1255
NSP Gasket (CAB(UP BOT)) SEB1294
NSP Gasket (CAB(DUCT-BOT)) SEB1295
NSP Gasket (CAB(UP WF DUCT-UP)) SEB1296
Gasket (INP-BACK) SEC1724
NSP Gasket (CAB SHORT) SEC1965
NSP Gasket (CAB LONG) SEC1966
NSP Gasket (CAB BIRI-SHORT) SEC1967
NSP Gasket (CAB TW) SEC1968
NSP Gasket (G-B BIRI-SHORT UP) SEC1969
NSP Gasket (G-B BIRI-LONG) SEC1970
NSP Gasket (G-B BIRI-SHORT BOT) SEC1971
Gasket (CAB BIRI-LONG) SEC1972
NSP Gasket (MDF BAR) SEC1973
NSP Felt (CB(INP WF)) SED1113
Felt (BOSS(WF)) SED1123
NSP Felt (DUCT) SED1133
Tape (CAB(WF-SIDE)) SEH1076
Tape (GRILLE ASSY) SEH1077
Input Terminal SKX1097
NSP MDF Bar SLX1162
NSP Port Tube Ring 26 SMR1382
NSP Paper Tube 26 SMR1396
NSP Acoustic Absorbent (DUCT) SMT1243
NSP Acoustic Absorbent
(UP UP-B BOT)
SMT1297
NSP Acoustic Absorbent SMT1298
(UP UP-R WF INP BOT)
NSP Acoustic Absorbent SMT1299
(DUCT INP-S(ROLL))
NSP Label Serial (Model Label L,R) SRW1083
Speaker (Woofer) H132DC65-51F
Speaker (Tweeter) FK26AP32-51L
Gasket Set SME3674
NSP Gasket SEC1978
NSP Polyethylene Bag S2 SHL1309
NSP Accessories Set SME3676
NSP Polyethylene Bag S1 KHL1079
NSP Screws Set SME3677
Screw BMZ50P100FTB
NSP Polyethylene Bag S0 KHL1081
Speaker Wire Set SME3678
NSP Polyethylene Bag S0 KHL1081
NSP Speaker Wire SDS1189
NSP Bracket ASSY Set SME3679
Case SHA2513
Case SHA2514
Protection Sheet S1 SHC1831
Protection Sheet SHC1837
Protection Sheet SHC1838
Bracket (L-TOP) ASSY SXG1086
NSP Label (L-TOP) SAK1016
Gasket SEC1979
Gasket SEC1980
NSP Tape SEH1078
NSP Bracket (L-TOP) SNA1451
NSP Cover L-T SNN1049
Bracket (L-BOT) ASSY SXG1087
NSP Label (L-BOTTOM) SAK1017
Gasket SEC1979
Gasket SEC1981
NSP Tape SEH1078
NSP Bracket (L-BOTTOM) SNA1452
NSP Cover L-B SNN1050
Bracket (R-TOP) ASSY SXG1088
NSP Label (R-TOP) SAK1018
Gasket SEC1979
Gasket SEC1980
NSP Tape SEH1078
NSP Bracket (R-TOP) SNA1453
NSP Cover R-T SNN1051
Bracket (R-BOT) ASSY SXG1089
NSP Label (R-BOTTOM) SAK1019
Gasket SEC1979
Gasket SEC1981
NSP Tape SEH1078
NSP Bracket (R-BOTTOM) SNA1454
NSP Cover R-B SNN1052
For Packing
Mark No. Description Part No. Mark No. Description Part No.
