PDP-S38
BRACKET ASSY SET
(SME3679)
1
No.
1
Num.
SHA2513
Part Num.
22SHC1831
31SXG1089
41SXG1088
51
6
7
PROTECTION SHEET S1
BRACKET(R-BOT)ASS'Y
CASE
Part Name
BRACKET(R-TOP)ASS'Y
SHA2514 CASE
1SXG1086 BRACKET(L-TOP)ASS'Y
1SXG1087 BRACKET(L-BOT)ASS'Y
8 35cm ZTA-4301-48CL TAPE (CLEAR)
9
10
2SHC1838 PROTECTION SHEET
2SHC1837 PROTECTION SHEET
11 10cm ZTA-4301-12CL TAPE (CLEAR)
1
2
3
4
5
8
7
6
2
9
9
10
10
11
11
