Pioneer SC-LX83 Service Manual

5
SC-LX83
5
6 7 8
5
6 7 8
A
B
C
D
E
F
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
R1843, R1863, R1864, R1866 RS1/16SS101J Not used
R1867, R1869-R1874 RS1/16SS101J Not used
R1901, R1902 RS1/16SS101J Not used
R1808, R1809, R1812 RS1/16SS102J Not used
R1905, R1906 RS1/16SS102J Not used
R1801 RS1/16SS103J Not used
R1817, R1821, R1822, R1831 RS1/16SS104J Not used
R1832, R1834, R1835 RS1/16SS104J Not used
R1813 RS1/16SS105J Not used
R1868, R1892 RS1/16SS151J Not used
R1846, R1847, R1865 RS1/16SS470J Not used
R1830 RS1/16SS473J Not used
R1891 RS1/16SS680J Not used
R1833 RAB4CQ470J Not used
C1855 CCSSCH100D50 Not used
C1014 CCSSCH101J50 CCSSCH100D50
C1802, C1812 CCSSCH101J50 Not used
C173 CCSSCH102J50 CCSSCH100D50
C9037, C9038 CCSSCH471J50 CCSSCH330J50
C1826, C1833, C1835 CCSSCH471J50 Not used
C1810, C1811 CCSSCH8R0D50 Not used
C1807 CEVLW101M10 Not used
C1803, C1844 CEVW101M16 Not used
C9807, C9808 CKSQYB104K25 CKSQYB104K50
C1854 CKSQYB225K10 Not used
C9817, C9823, C9850 CKSRYB104K16 CKSRYB104K50
C1804 CKSRYB104K16 Not used
C1801 CKSRYB105K10 Not used
C632, C661, C937, C946 CKSSYB104K10 CKSSYB104K16
C969, C976, C1296, C1341 CKSSYB104K10 CKSSYB104K16
C1362, C1367-C1370, C1385 CKSSYB104K10 CKSSYB104K16
C9043, C9066, C9083, C9095 CKSSYB104K10 CKSSYB104K16
C9099, C9108ÅCC9110, C9214 CKSSYB104K10 CKSSYB104K16
C9215, C9221, C9225, C9243 CKSSYB104K10 CKSSYB104K16
C9253, C9255, C9306, C9308 CKSSYB104K10 CKSSYB104K16
C9533, C9569, C9589, C9595 CKSSYB104K10 CKSSYB104K16
C9600, C9894, C9896 CKSSYB104K10 CKSSYB104K16
C1805, C1806, C1808, C1809 CKSSYB104K10 Not used
C1813Å[C1815, C1819 CKSSYB104K10 Not used
C1820, C1825, C1832, C1834 CKSSYB104K10 Not used
C1852, C1853 CKSSYB104K10 Not used
C143, C144, C418, C9024 CKSSYB105K6R3 DCH1246
C9035, C9042, C9859, C9870 CKSSYB105K6R3 DCH1246
C406, C611, C9362 Not used CCSSCH100D50
C759, C760 Not used CCSSCH101J50
Mark Symbol and Description AWX9620 AWX9627 Remarks

Pioneer SC-LX83 Specifications

General

Channels	7.1
Amplification Type	Class D
HDMI Inputs	6
HDMI Outputs	2
HDMI Version	1.4a
3D Support	Yes
Audio Return Channel (ARC)	Yes
Audio Decoding	Dolby TrueHD, DTS-HD Master Audio
Network Connectivity	Ethernet
iPod/iPhone Compatibility	Yes (via USB)
AirPlay	No
USB Port	1 (Front)
Wi-Fi	No
Bluetooth	No
Frequency Response	5 Hz-100 kHz
Signal-to-Noise Ratio	106 dB
THX Certified	THX Ultra2 Plus
Network Features	Internet Radio
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Input Sensitivity	200mV
Power Output per Channel	140 W (8 ohms, 20 Hz-20 kHz, THD 0.08%, 2ch Driven)
