XR-A790, XR-A390
14
AF ASSY
F
F
XWZ3288 and XWZ3297 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3297 XWZ3288
IC5751 BU1923F Not used
Q5751 2SA1037K Not used
Q5752 DTC124EK Not used
L3333, L3334 ATH-133 Not used
L3991 Not used XTL3001
L5751 XTL3002 Not used
C1997, C3329, C3330 CKSRYB103K50 Not used
C2327–C2330, C3321, C3322, C3852, C3854 CCSRCH470J50 Not used
C3001, C3002, C3858 CCSRCH101J50 Not used
C3023, C3024 CFTLA564J50 CFTLA474J50
C3025, C3026 CKSRYB104K16 CKSRYB683K16
C3027, C3028 CFTLA334J50 CFTLA154J50
C3029, C3030 CKSRYB563K16 CKSRYB273K16
C3043, C3044, C3082 CEATR47M50 CEAT2R2M50
C3051, C3052, C3853, C3855 CKSRYB472K50 Not used
C3073–C3076 CKSRYB122K50 Not used
C3081 CEAT4R7M50 CEAT100M50
C3091 CEAT2R2M50 CEAT100M50
C3319, C3320 CCSRCH6R0D50 CCSRCJ3R0C50
C3335–C3338 CKSRYF104Z25 Not used
C3345, C3346 (0.01µF) ACG7021 Not used
C3850 CKSRYB473K16 Not used
C3994, C3995 CCSRCH681J50 Not used
C5751, C5752, C5755 CCSRCH270J50 Not used
C5753 CKSRYB103K50 Not used
C5754 CEAT330M16 Not used
C5756 CCSQCH561J50 Not used
C5757 CCSRCH271J50 Not used
C5758 CEAT100M50 Not used
R3333, R3334 RD1/4LMF101J RD1/4LMF100J
R3335, R3336 RS1/16S100J Not used
R3509 RS1/16S393J RS1/16S473J
R3515–R3518 RS1/16S152J RS1/16S122J
R5751 RS1/16S223J Not used
R5752 RS1/16S222J Not used
R5753 RS1/16S101J Not used
R5754 RS1/16S102J Not used
X5751 CRYSTAL RESONATOR (4.332MHz) ASS7004 Not used
To Next Page
