XR-A790, XR-A390
15
AWU7797, AWU7791 and XWZ3311 are constructed the same except for the following :
PRIMARY ASSY
F
H
Mark Symbol and Description
Part No.
Remarks
XWZ3311 AWU7797 AWU7791
Q5656-Q5658 2SC2412K 2SC2412K Not used
D5561, D5562 1SS181 1SS181 Not used
D5593 1SS133 1SS133 Not used
D5594 1SS355 Not used Not used
D5595, D5596 1SS355 Not used Not used
D5601-D5608, D5622 SLP3118C51H SLR-343MC(NPQ) Not used
D5610, D5611, D5615, D5616, D5904 SLP3118C51H SLR-343MC(NPQ) SLR-343MC(NPQ)
D5612, D5614 SLP6118C51H SLR-343DC(NPQ) SLR-343DC(NPQ)
D5617 SLP6118C51H Not used Not used
D5618 SLP3118C51H Not used Not used
D5619, D5620, D5903 SLP9118C51H SLR-343VC(NPQ) SLR-343VC(NPQ)
D5621 SLP6118C51H SLR-343MC(NPQ) Not used
D5652-D5655, D5657, D5658 1SS355 1SS355 Not used
D5902 SLP7118C51H SLR-343PC(KLM) SLR-343PC(KLM)
S5911, S5913, S5915–S5921, S5923–S5929 XSG3001 ASG1051 ASG1051
S5931–S5940 XSG3001 ASG1051 ASG1051
C3909 CKSRYB472K50 Not used Not used
C3913 CCSRCH471J50 Not used Not used
C3915 CCSRCH470J50 Not used Not used
C3920, C3921 CCSRCH101J50 Not used Not used
C3922 CKSRYB561K50 Not used Not used
C3951, C3952 CKSRYB103K50 Not used Not used
R3908 RS1/16S122J RS1/16S101J RS1/16S101J
R5518 RS1/16S102J Not used Not used
R5561, R5562 RS1/16S152J RS1/16S152J Not used
R5570, R5571 RS1/16S473J RS1/16S473J Not used
R5601, R5613, R5617 RD1/4PU151J RD1/4PU151J Not used
R5618, R5620, R5622 RS1/16S222J RS1/16S222J Not used
R5619, R5621, R5623 RS1/16S330J RS1/16S330J Not used
R5702, R5704 Not used RS1/16S223J RS1/16S223J
R9901, R9902 Not used RS1/16S101J Not used
CN2901 FFC CONNECTOR HLEM15R-1 HLEM15R-1 HLEM13R-1
XWZ3291, XWZ3294 and XWZ3312 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3312 XWZ3291 XWZ3294
S1 VOLTAGE SELECTOR Not used XKX3001 Not used
L1 LINE FILTER ATF1136 Not used Not used
H3–H6 FUSE CLIP Not used AKR7001 Not used
DISPLAY ASSY
F
I
