Pipishell PIMFK1 - Step 4: Mount TV to Wall Mount; Attach and Secure TV; Locking Mechanism

3B-3
A3
Install wall plate using lag bolts A1, washers A2 and anchors A3.
Tighten the lag bolts until they are pulled firmly against the wall plate.
Mounting your TV to the Brackets and lock it.
Step 4
Use the hammer to knock
anchors A3 into the wall.
1
2
A2
A3
5
