Page: 29
x6
x3
Fixings Pack #10
4
WALL
Assemble your GeeFix wall anchor system by
threading the supplied pullcord through the
round wall plug, the curved back plate, and
back through the wall plug.
While holding onto the pullcord, feed the
curved back plate into the hole and centre
on the 1″ hole.
While keeping light tension on the pullcord
slide the wall plug into the 1″ hole to align
with the holes on the back plate.
While keeping rm tension on the pullcord,
screw the large screw into the centre hole
until the GeeFix becomes rm, but do not
over tighten. Keeping tension on the
pullcord will keep the back plate in place
during installation.
GeeFix Fixings
Pull out the pullcord but do not discard. You
can use the same pullcord on additional
GeeFix.
Screw in the 2 smaller screws on either side
of the large screw and tighten until the
GeeFix is rmly secured but do not over
tighten.
Remove the centre screw
3
To Next Page
