Chapt II : Use notice
1. Set up
Before lifting your car, you must set up the jack.
Firstly, if you chose the layout with the pin limiter, you must set up the pin range at the right
distance to allow you to lift your car without any damage on it. This step needs to be done only
one time before the first use until changing car. Be sure that the pin will be in the car lifting tube
at least for 120mm even if you don’t use the pin limiter.
You can also setup the high stop of the part named 1 on the picture below by screwing the high
stop screw in one of the 3 holes marked with red arrows. Use Loctite 243 with a 4N.m torque to
stick the screw.
2. Normal use
To use the product quickly, unlock the pin and plug it into the car lifting tube. Get the pin inside
the tube by at least 120mm.
