3. Description of the appliance
WARNING! Remove the safety bolts before initial use (see chapter 2.3
REMOVING OF THE SHIPPING BOLTS); otherwise, the appliance may cause
serious injury to persons and / or severe damage to the appliance.
3.1 Washer-dryer
Fig. similar: modifications are possible.
1
POWER CABLE / POWER PLUG
2
DETERGENT DISPENSER
3
CONTROL PANEL
4
DRUM
5
COVER of the drain pump filter / DRAIN PUMP FILTER
6
WATER INLET VALVE
7
DOOR of the appliance
8
WATER DRAIN HOSE
9
ADJUSTABLE FEET
