Rear View of the Product
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨
①
Power Input
②
Up-stream USB 3.0 port (to PC)
③
USB port-A (support USB 3.0 plug play device)
④
USB port-B (support USB 3.0 plug play device)
⑤
DisplayPort Input (DisplayPort 20 pin)
⑥
HDMI input (HDMI 19 pin)
⑦
VGA Input (D-Sub 15 pin)
⑧
Audio Input
⑨
Headphone Jack
7
