Technical Information
Specifications
LCD Panel
Size 22W"
Display Type Active matrix color TFT LCD
Resolution 1680 x 1050
Display Dot 1680 x (RGB) x 1050
Display Color 16.2M with FRC or Dithering
Video
Input Signal Analog RGB 0.7Vp-p
Digital TMDS
Input Impedance 75 Ohm ± 2%
Polarity Positive, Negative
Amplitude 0 - 0.7 ± 0.05 Vp
Multi-mode Supported
Horizontal Frequency: 30 ~ 83 kHz
Vertical Frequency: 56 ~ 75 Hz
30~80kHz
56~75Hz
Control
Power switch (hard and soft types) On/Off switch with LED indicator
Audio
Input 500mVrms
Output 1W +1W
OSD
Brightness Digital
Contrast Digital
Horizontal Position Digital
Vertical Position Digital
Phase Digital
Clock Digital
Display Mode Setup
Use EEPROM to save settings in memor.
