14
SYNC
WIDTH
FRONT
PORCH
BACK
PORCH
TIMING NAME
FH (KHz)
FV (Hz)
SYNC
POLARITY
TOTAL/ ACTIVE
(DOT / LINE)
(DOT / LINE)
PIXEL
FOREQ.(MHz)
1024x768 60.023 + 1312 1024 96 16 176
VESA-768-75Hz 75.029 + 800 768 3 1 28
78.75
1024x768 60.24 – 1328 1024 96 32 176 80
1152x864 54.054 + 1480 1152 96 40 192
(60Hz) 59.27 + 912 864 3 13 32
80
1152x864 63.851 + 1480 1152 96 32 200
(70Hz) 70.012 + 912 864 3 1 44
94.499
1152x864 67.5 + 1600 1152 128 64 256
(75Hz) 75 + 900 864 2 2 32
108
1152x870 68.68 – 1456 1152 128 32 144
(75Hz) 75.06 – 915 870 3 3 39
100
1280x720 44.772 – 1664 1280 128 64 192
(60Hz) 59.855 + 748 720 5 3 20
74.5
1280x960 60 + 1800 1280 112 96 312
(60Hz) 60 + 1000 960 3 1 36
108
1280x960 70 + 1800 1280 112 96 312
(70Hz) 70 + 1000 960 3 1 36
126
1280x960 75 + 1800 1280 112 96 312
(75Hz) 75 + 1000 960 3 1 36
135
1280x1024 64 + 1688 1280 112 48 248
VESA-1024-60Hz 60 + 1066 1024 3 1 38
108
1280x1024 80 + 1688 1280 144 16 248
VESA-1024-75Hz 75 + 1066 1024 3 1 38
135
1360x768 75 + 1792 1360 112 64 256
60Hz 75 + 795 768 6 3 18
85.5
1440x900 55.469 + 1600 1440 32 48 80
Red. BLKing 60Hz 59.901 – 926 900 6 3 17
88.75
1440x900 55.935 – 1904 1440 152 80 232
60Hz 59.887 + 934 900 6 3 25
106.5
1440x900 70.635 – 1936 1440 152 96 248
75Hz 74.984 + 942 900 6 3 33
136.75
1680x1050 64.674 + 1840 1680 32 48 80
Red. BLKing 60Hz 59.883 – 1080 1050 6 3 21
119
1680x1050 65.29 – 2240 1680 176 104 280
60Hz 59.954 + 1089 1050 6 3 30
146.25
1680x1050 82.306 – 2272 1680 176 120 296
75Hz 74.892 + 1099 1050 6 3 40
187
Note :
DVI can not supporting 1680x1050@75Hz. Mode 640x350, 640x400 and 720x400 will locate on middle position but
cannot be expanded to full screen on vertical direction.
