Planar PLL2450MW User Manual

Content
Operation Instructions ............................................................................................................................................... 1
Unpacking Instructions .............................................................................................................................................. 3
Safety Precautions ....................................................................................................................................................... 3
Consignes de sécurité ................................................................................................................................................. 4
Package Overview ........................................................................................................................................................ 5
First Setup ....................................................................................................................................................................... 6
Front View of the Product ......................................................................................................................................... 7
Rear View of the Product ........................................................................................................................................... 8
Quick Installation .......................................................................................................................................................... 9
Basic Operation .......................................................................................................................................................... 10
Advanced Operation—OSD Menu ...................................................................................................................... 12
Supporting Timing Modes ..................................................................................................................................... 15
Technical Information .............................................................................................................................................. 16
Wall-Mount Installation Instructions .................................................................................................................. 17
Care and Maintenance ............................................................................................................................................ 18
Troubleshooting ........................................................................................................................................................ 18
Planar Support ........................................................................................................................................................... 19

Planar PLL2450MW Specifications

General

Pixel pitch	0.2715 x 0.2715 mm
Screen shape	Flat
Response time	12.5 ms
Backlight type	Edge LED
Display surface	Matt
Display diagonal	23.6 \
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	76 Hz
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
RMS rated power	2 W
Number of speakers	2
AC input voltage	100 - 240 V
Power consumption (standby)	0.5 W
Power consumption (typical)	18.5 W
Certification	FCC-B, CE, UL/cUL, RoHS
Product color	Black
Cables included	AC, HDMI

Weight and Dimensions

Stand weight	3850 g
Depth (with stand)	170.4 mm
Width (with stand)	547.6 mm
Height (with stand)	405.5 mm
Weight (with stand)	3120 g
Depth (without stand)	40.9 mm
Weight (without stand)	2870 g
