7
Connecting the Display
Swivel Range : 350˚
350
Height Range : maximum 100.0 mm (3.94 inch)
* Please be sure to
remove the Locking
pin to adjust the height.
100.0 mm
ERGONOMIC
I
t is recommended that in order to maintain an ergonomic and comfortable viewing position, the forward tilt
angle of the monitor should not exceed 5 degrees.
WARNING
You do not need to replace the Locking pin after it is removed, to adjust its height.
