Basic Operation and Calibration/Reset Instructions
Before using the Touchscreen LED Monitor:
Connect external equipment properly.
Insert the power plug, and the power LED indicator will light orange.
Power On/Off
To turn the Touchscreen LED Monitor on/off:
Press POWER button on the front. The power LED indicator light will be blue when the
Touchscreen LED Monitor is on.
Using the OSD Menu
Use OSD menus to adjust settings by using the menu button on the front of the Touchscreen
LED Monitor.
Displays main menu
1
Exits from OSD menu
2 Selects between VGA, DVI, HDMI or Auto mode
Select the desired item when in OSD menu
▼
When not in OSD menu, directly enters Volume adjust
Select the desired item when in OSD menu
▲
When not in OSD menu, directly enters Preset Mode
▼ + ▲ Recalls both Contrast and Brightness (when not in OSD menu)
OSD Lock Out Function
When Touchscreen LED Monitor is in normal mode, the “OSD Lock Out” function can be enabled.
Option 1: OSD lock – all 4 buttons are locked except the “POWER” button.
Press and hold the 1 button and the ▲ button for 10 seconds to lock the OSD buttons.
The Touchscreen LED Monitor will show an “OSD Lock Out” message for 3 seconds and the
message will disappear automatically.
Repeat this step to unlock.
6
English
