Planet 2.4GHZ DIGITALREMOTE CONTROL SYSTEM User Manual

12
Planet•
rock-solid r/c
HELICOPTER MODE 1
▼ Each dual axis stick unit of your transmitter controls 2 helicopter functions (complete with trimmers on
each function) giving you control about all 4 axes of flight).
Rotate
nose right
Rotate
nose left
Forwards
Backwards
Crab
right
Crab
left
Climb
Descend
▼ The right stick operates the throttle (main rotor speed) and the roll ‘cyclic’ steering controls which moves
the to the left/right in the horizontal plane.
Climb
Descend
Crab
right
Crab
left
▼ The left stick operates both yaw control and the forwards/backwards 'cyclic' steering controls.
Rotate
nose right
Rotate
nose left
Forwards
Backwards
