Figure 2.3 ES-10024/ALV-9610 Dimensions
8.63
4.122
4.118
.50
.81
2.44
.669
1.42
2.00
5.25
25
90
4.00
5.25
4.122
Aircraft Alternator
Maintenance Manual
ES1031 24-30-01
Rev. A: 11 Aug. 2021 Page: 2-3
