B. Operational Data
Gear Driven -
Air Cooled -
Belt Driven (ES10024B) -
External fan cooling (ES10024B) -
Operating Speed (Minimum for Regulation): 2,200 RPM
Maximum Continuous Operating Speed: 10,000 RPM
Operating Output (Rated): 28.0 volts, 100 amps
Maximum Operating Altitude: 31,900 feet MSL (9,723 meters MSL)
Weight: See Table 2-1, this chapter
C. Dimensions
(1) The basic dimensions of each alternator are shown in Fig. 2.3 thru 2.10.
(2) The dimensions of the ALV-9610 alternator are the same for the ES-10024 alternator with the exception
of the flex cooling duct.
Aircraft Alternator
Maintenance Manual
24-30-01 ES1031
Page: 2-2 Rev. A: 11 Aug. 2021
© 2021 - Hartzell Engine Technologies - All rights reserved
