Aircraft Alternator

Maintenance Manual

24-30-01 ES1031

Page: 2-6 Rev. A: 11 Aug. 2021

Figure 2.7 ES-10024B-4 Dimensions

7.61

1.978

2.52

3.00

K 6.290 STD

Figure 2.8 ES-10024B-5 Dimensions

9.393

2.44

2.266

1.883

J10 2.31 PITCH Ø
