Table 5.2 - ES- 10024B Test Parameters
Table 5.3 - ES- 6024D Test Parameters
Order of Tests Output Voltage Min. Output Amps Max Alternator RPM
Test #1 28.0 ± .5 100 8000
Test #2 28.0 ± .5 65 4000
Test #3 28.0 ± .5 10 2500
Table 5.1 - ES- 10024 & ALV-9610 Test Parameters
Order of Tests Output Voltage Min. Output Amps Max Alternator RPM
Test #1 28.0 ± .5 100 8000
Test #2 28.0 ± .5 65 4000
Test #3 28.0 ± .5 10 2500
Order of Tests Output Voltage Min. Output Amps Max Alternator RPM
Test #1 28.0 ± .5 65 8000
Test #2 28.0 ± .5 54 4000
Test #3 28.0 ± .5 27 2500
Aircraft Alternator
Maintenance Manual
24-30-01 ES1031
Page: 5-6 Rev. A: 11 Aug. 2021
© 2021 - Hartzell Engine Technologies - All rights reserved
