Aircraft Alternator
Maintenance Manual
ES1031 24-30-01
Rev. A: 11 Aug. 2021 Page: 6-11
© 2021 - Hartzell Engine Technologies - All rights reserved
Figure 6.4 - AUX, Output, & Ground Terminal Stud Assembly
Output (+) Terminal
Aux Terminal
Nut
Flat Washer
AUX Terminal Stud
Lock-washer
Insulator
Fiber Washer

Mounting
Plate

Mounting
Plate
Output (+) Terminal Stud
Nut
Lock-washer
Flat Washer
Fiber Washer
Bushing
Washer
Bushing
Capacitor
Ring
Terminal
(ES-10024
Only)
Ground Terminal
Ground Stud
Cupped Nut 2 ea.
Washer AN960-10
Field Terminal(s)
Thin Washers
2 ea.
Lock Washer
Nut
Brush Holder Assembly
