Step 3: Please align the screw holes on the HDD with those on the HDVR case and secure
them with the given screws.
Step 4: After the HDD is secured, it should look like the one in the pictures (front and
back) below:
Contents
Quick Installation Guide x 1 Power Adapter x 1 USB Mouse x 1
CD Disk x 1 SATA Cable x 1 Foot Pad x 4
RS485 Connector x 1 SATA Power Cable x 1 Screw Kit x 1
*
SATA cable and SATA power cable are included in the HDVR
Hard Disk Installation
Caution
Before installing the HDD, please make sure there is no pre-congured
partition in this HDD. If yes, please delete all the partitions before the
installation.
Step 1: Remove the upper case.
Step 2: Plug the HDD power cable and SATA cable into the slot of the PCBA board and the
HDD, respectively, making sure the connections are well done.
Hardware Connection
HDVR-830
HDVR-430
HDVR-1630
Name Description
V1-V16 Composite video broadcast signal (CVBS) input interface.
A1-A4 The input interface of the audio signal.
A-OUT The output interface of the audio signal.
LAN The network interface of RJ45.
HDMI The output interface of the HDMI video signal.
VGA The output interface of the VGA video signal.
Power 12V DC, 2A
485+/485- The interface of the alarm input, the alarm output and RS485.
To Next Page
