Once POE-161 detects the existence of an IEEE 802.3at device,
the POE In-use LED indicator will be steady on to shows it is
providing power.
If the connected device is not fully complying with
IEEE 802.3at Power over Ethernet pre-standard or
in-line power device, the LED indicator of POE-161
will not be steady on.
POE-161 and POE-161S, the IEEE 802.3at Injector Splitter
Installation
1. Connect the AC adapter to “DC 56V” of POE-161. The power
LED will be steady on.
2. Connect a standard network cable from
“Ethernet+DC” port
of POE-161 to “PoE In” port of POE-161S. The POE In-use
LED of POE-161 / POE-161S will light on continuance.
3. Connect a standard network cable from Switch/workstation to
“Ethernet” port of POE-161.
4. Connect the UTP cable in the package from
“Ethernet” port
of POE-161S to the RJ-45 port of remote device.
5. Adjust proper DC power output and connect DC plug from
“DC OUT” of POE-161S to remote device.
6. Power on the remote device and its power LED indicator will
remains on.
