Quick Installation Guide
- 3 - PLANET Technology Corp.2024
1. Package Contents
Thank you for purchasing PLANET Industrial Wall-mount Managed
Gigabit Switch, WGS-804HPT or WGS-4215 series. The table below
shows the models with the number of ports:
Model Name
10/100/1000T
Copper Ports
802.3at PoE
Ports
100/1000 SFP
Fiber Optic Interface
WGS-4215-8T 8 - -
WGS-4215-8T2S 8 _ 2
WGS-804HPT
8 4 -
WGS-4215-8P2S 8 8 2
WGS-4215-16P2S 16 16 2
In the following section, unless specified, the term “Wall-mount Managed
Switch” mentioned in this quick installation guide refers to the above
models.
Open the box of the Wall-mount Managed Switch and carefully unpack it.
The box should contain the following items:
The Wall-mount
Managed Switch x 1
Quick Installation
Guide Sheet x 1 pc
Wall-mounted Kit x 1
set
(Vary on the model)
DIN-rail Kit x 1 set Magnet Kit x 1 set 3-pin Terminal Block
Connector x 1 pc
