Plantronics T10 User Manual

6
STEP 2
7
STEP 3
The Headset included with the T10 Headset Telephone
can be used with the Adjustable Headband or with one of the
Ear Hooks.
HEADBAND USE
Snap the Adjustable Headband into the back of the Headset
Assembly . Press the Ear Cushion Assembly onto the Headset
Assembly , aligning the notch in the ring with the Voice
Boom.
Place the Headset on either ear and adjust the Headset to a
comfortable position by moving the Adjustable Headband.
Position the Voice Boom near the corner of your mouth.
EAR HOOK USE
Press the Pivot Ball Ring onto the Headset Assembly.
Insert one of the Ear Hooks into the Pivot Ball. You may
need to try each size to find the most comfortable fit. Slip the
hook over your ear and position the Voice Boom near the corner
of your mouth.
CLOTHING CLIP
The Clothing Clip keeps the Headset free from the weight of the
cord. Attach the clip to your clothing at about chest level. Allow
enough slack in the cord (approximately 6 inches) to permit your
head to move without pulling on the Headset or the Clothing Clip.
You are now ready to make or receive calls.
19
23
2124
22
20
22
21
2521
20
USING THE HEADSET
A
B
C
D
With the Headset in position, place a call by pressing the
On/Off Button (In-use Indicator and On Line Indicator
Lights are on). Listen for dial tone.
Dial the desired number using the Twelve Button Dial Pad.
When your party answers, speak normally. If your party cannot
hear you, see Troubleshooting (page 12).
Adjust the Listen Volume Control as needed to hear the
other party.
13
3
2
1211
E
PLACING A CALL
RECEIVING A CALL
With the Headset in position, when the ringer notifies you of
an incoming call, press the On/Off Button to answer the call
(In-use Indicator and On Line Indicator Lights are on).
2
12
11
T10 Final w_warranty 4/20/00 4:09 PM Page 16
