3. TECHNICAL DATA
Input Voltage AC 220-240V, 50Hz
Input Power 600W
Degree of protection IP54
Norms EN 60335-1
EN 60335-2
EN 12050-2
Max water temperature 100 °C
Performances See Fig.6
Discharge hose 40 mm
4. PLUMBING INSTALLATION
4a Connection of the appliances (Fig. 1)
Geyser can collect any wastewater coming from the appliances (except for the
WC) through the available lateral connection.
Connect the appliance to the inlet lateral connection of Geyser and fix with the
supplied hose clamp using a screwdriver. In case of multiple devices, connect
them through a manifold (not supplied).
Wastewater coming from all appliances must have a 3% minimum fall in
reaching the unit (Fig. 2).
WARNING (Fig. 3): when installing a shower, ensure that the underside of the
shower tray is at least 20cm above floor level (please note that the
recommended fall is 3% in reaching the Geyser lateral connection).
4b Connection of discharge pipework
Connect the discharge pipe into the rubber discharge pipe positioned on the
side of the unit and secure it with the provided hose clamp (32-50mm).
