11
D2020N User Guide
Programs
0: Liquid Electrolyte Battery with Low Battery Disconnect option (p.18)
1: Sealed batteries (AGM or Gel) with Low Battery Disconnect option
2: Liquid Electrolyte Battery with Light Controller option (see p.19)
3: Sealed batteries (AGM or Gel) with Light Controller option.
4: Customised setup. Choosing this program will require you to set a
number of additional parameters. (see Reference Manual)
d. When battery voltage is correct, long-push to set it.
3. Set your program (! Important)
The Dingo comes with a number of pre-set programs, to
make configuration easy for most installations.
a. Short-push to move from “VOLT” to “PROG”.
b. Long-push and the program number will start flashing.
c. Short-push to select the best program for your batteries:
d.
When the program shown is correct, long-push to set it.
4. Set the Battery Capacity
Note: BCAP setting does not affect battery charging.
a. Short-push to move from “PROG” to “BCAP”.
b. Long-push and the battery capacity will start flashing.
c
. Short-push to choose the correct battery capacity for your
system in Ampere hours (Ah). (Settings over 1000Ah display
in thousands - e.g. 1600 Ah shows as “1.6”. Note: Look for
the decimal point, eg 20=20Ah, 20.0=20,000Ah) If unsure,
check your battery manual or consult your battery supplier.
d. Long-push to keep the chosen value
