D2020N User Guide
Specifications
Nominal system voltages 12,24,32,36,48 V
Maximum voltage BAT+ to BAT- 100 V
Maximum short term voltage BAT+ to BAT- (2 minutes) 120 V
Maximum voltage SOL+ to BAT- (for a 48V system) 100 V
Maximum voltage LOAD+ to BAT+ 70 V
Maximum voltage between the ‘G’ relay terminals 90 V
Maximum voltage B+ sense to BAT+ +/- 30 V
Maximum continuous charge current (SOL+) 20 A
Maximum continuous load current (LOAD+) 20 A
Maximum short term load current (5 minutes) 30 A
Maximum ‘G’ relay contact current 300 mA
Battery temperature sensor operating range -20 to +70
o
C
Maximum storage temperature 70
o
C
Supply current (device only, battery at 12V) <13 mA
Supply current (device only, battery at 60V) <16 mA
Maximum supply current (with accessories) 27 mA
Meter accuracy <+/-2% +/- 1 digit
Maximum wire entry size (large terminals) 16mm
2
(6 AWG)
Wire size, Green terminal block 0.2-1.3mm
2
(26 -16 AWG)
