D2020N User Guide
22
Settings Used in
Programs 0-3
When programs 0-3 are
selected, the controller
automatically uses the values
in the table on the right to
control its operation.
The voltage settings are
shown correct for 12V
operation. For higher
voltages, scale these up (eg.
for a 24V system, multiply
each voltage figure by 2.)
CHRG
Setting for program number
Parameter 0 1 2 3
GMOD 0
G ON (V) 11.5
GOFF (V) 13.8
GDEL (Min) 10
GEXD (Day) 30
GRUN (Hr) 1.0
LOAD
Setting for program number
Parameter 0 1 2 3
LOFF (V) 11.3
L ON (V) 12.8
LDEL (Min) 10
SET/REG
Setting for program number
Parameter 0 1 2 3
BMAX (V) 15.0 14.2 15.0 14.2
EMAX (V) 16.0 14.0 16.0 14.0
ETIM (Hr) 1.0 0 1.0 0
EFRQ (day) 45
ABSV (V) 14.0
ATIM (Hr) 2.0
FLTV (V) 13.8
HYST (V) 0.4
BRTN (V) 12.3
CHRG (A)
20
BFRQ (Day) 15
TCMP 0
