D2020N User Guide
4
Screw wires into the high current terminals
tightly in the order listed on page 6.
Fig. 1
Warning: This controller is for DC current ONLY

BOOST
Display
Alarm LED
Terminals for G and sensor wires
(plug in terminal block)
Accessory port
Mounting holes
Cable tie
posts
T
Test terminal
Ah
Button
See page 8
