LEG INSTALLATION (If required)
Before Installing Heater, Follow These Steps for leg Installation.
2. With assistance, carefully place stove on its top onto the padded surface.
3. Insert the holes of a leg into the two (2) Threaded Studs shown in Figure 0.1.
4. Tighten the nuts securely (DO NOT over tighten) to the Threaded Studs.
5. Repeat steps 3-4 to install the other three (3) legs.
6. With assistance, lift the stove off of the padded surface, and set upright onto the newly installed legs.
Nut
Threaded Studs
BATTERY INSTALLATION
Step 1 – Locate the Push Button Ignitor by lowering the cover on the bottom of the stove. (Fig. 1)
(Fig. 2)
Step 3 – Insert the battery with the positive (+) side facing forward.
Push Button Ignitor
Cover
Push Button
Ignitor
Push Button
Cap
AAA Battery
