operating manual BAIndustrie_UK 19
HP 600/xx / HP 620/xx
(30 = 100,5 mm; 37 = 110,5 mm; 40 = 110,5 mm; 50 = 118,5 mm)
The motor is fixed with 4 M6 bolts.
Maximum screw-in depth: 12 mm
Maximum tightening torque: 10 Nm
HP 6
00
/ HP 620
