operating manual
BAIndustrie_UK
20
HP 600/xx
W
K; HP 620/xx
W
K
(40 = 108,5 mm; 50
= 118,5 mm)
The motor is fixed w
ith 4 M6
bolts.
Maximum screw
-in depth: 12 mm
Maximum tightenin
g
torque: 10 Nm
