2. Getting to know the Model 82
Take a few minutes to become familiar with the main components
of the Model 82.
1. Output wheels 7. Power switch
2. Belt stacker 8. Ground fault interruptor (GFI )
3. Control panel 9. Power cord receptacle incl. fuses
4. Top cover 10. Connection cable outlet
5. Docking assembly 11. Base
6. Back jogger adjustment screw
2.1 Main components
2
3
4
5
7
8
9
1
11
2-1
6
