Stapler Folder Model 82 Operator Manual
T10136
1
2.2 Control panel
1. Auto mode indicator 9. Stacker full indicator
2. Manual mode indicator 10. Staple(s) missing indicator
3. Staple and fold mode indicator 11. Manual / Auto mode button
4. Fold mode indicator 12. Program select button
5. Edge stapling mode indicator 13. Run / Adjustment mode button
6. Run mode indicator 14. Length adjustment button, decrease
7. Adjustment mode indicator 15. Length adjustment button, increase
8. Paper jam indicator
23 645 7 8910
11 12 13 14 15
2-3
