26
Appendix B: Specifications
4
Image Sensor CIS x 2
Optical Resolution 600 dpi
Hardware Resolution 600 x 600 dpi
Scan Modes
Color: 48-bit Input; 24-bit Output
Grayscale: 16-bit Input; 8-bit Output
B/W: 1-bit
Scanning Speed
Simplex: 5 sec (Color, 300 dpi, A6)
Duplex: 7 sec (Color, 300 dpi, A6)
Scanning Area (W x L)
Max: 104.9 x 593.3 mm (4.13" x 23.36")
Min: 40 x 45 mm (1.57" x 1.77")
Acceptable Paper Sizes (W x L)
Max: 107 x 593.3 mm (4.21" x 23.36")
Min: 40 x 45 mm (1.57" x 1.77")
Acceptable Paper Weight
(Thickness)
Paper: 50 g/㎡ to 120 g/㎡
Plastic card: Non-Embossed up to 1.0 mm &
Embossed up to 1.2 mm
Action Button Scan
Power Supply USB Power: 5V / 0.5A
Interface USB 2.0
Net Weight 0.45 Kgs (1 Lbs)
Dimensions (W x D x H) 194 x 75 x 55 mm (7.63" x 2.95"x 2.17")
Protocol TWAIN Compliant
4
Hardware specifications may change at any time without prior notice.
