706303/081915/A Wireless Control System
4
PREFACE
Using this manual
This manual is intended to be used as a work of reference for
professional, well trained and authorized users to be able to
safely install, use, maintain and repair the product mentioned on
the cover of this document. This user manual should always be
kept with the product, as well as a duplicate copy be kept by the
fi re department or city service department after installation.
Pictograms and symbols
The following pictograms and symbols are used in this manual:
ATTENTION
A remark with additional information for the user. A
remark brings possible problems to the user’s
attention.
CAUTION!
Procedures, if not carried out with the necessary
caution, could damage the product, the workshop or
the environment.
WARNING!
Procedures which, if not carried out with the
necessary caution, may damage the product and/or
cause serious personal injury.
CAUTION!
Risk of electric shock.
WARNING!
Fire hazard! Important warning to prevent fi re.
Text Indicators
Listings indicated by “-” (hyphen) concern enumerations.
Listings indicated by “•” (bullet point) describe steps to perform.
Service and Technical Support
For information about specifi c adjustments, maintenance or
repair jobs which are not dealt with in this manual, please
contact the supplier of the product. Make sure you have the
following specifi cations at hand:
- product name
- Sales order sold on
- Unit using in conjunction with, for example, an OS-3
You can fi nd this data on the identifi cation plate.
1 INTRODUCTION
1.1 General Description
The Wireless Receiver and Transmitter system add-on is
designed to meet all local laws for radio frequency use. This
system allows simple and expandable wireless integration with
all Plymovent control systems.
1.2 Product Combinations
This product can be used in conjunction with all Plymovent
control boxes and most Plymovent remote triggering systems.
1.3 Technical Specifi cations - Receiver
L x W x H 6” x 4.5” x 2.5” (152.4mm x
114.3mm x 63.5mm)
Mounting Hole Diameter Slotted, hole diameter 1” (25.4mm),
slot .25” (6.35mm)
Mounting Hole Location Slots 7.5” (190.5mm)
OC centered
along 4.5” (114.3mm) profi le
4 corner mounting holes 6 5/8” x 3
1/4” (168.27mm x 82.55mm)
Weight 2 lbs (.907 kg)
Box Rating NEMA 12
Compliant With UL listed enclosure, unit operates at
24 VAC and does not require UL
compliance*
Input Power 12-24 V DC/AC
*For most up-to-date UL information, including on Plymovent,
please visit the online certifi cations directory at www.ul.com.
1.4 Technical Specifi cations - Transmitter
L x W x H 2.375” x 1.5” x .5” (60.325mm x
38.1mm x 12.7mm)
Weight 1 oz. (.028 kg)
Input Power 3 VDC Battery
Refer to the available product data sheet for detailed
product specifi cations.
1.5 Ambient Conditions
Operating temperature:
- min.
- nom.
- max.
- 41°F (5°C)
- 68°F (20°C)
- 104°F (40°C)
Max. relative humidity 80%
Storage conditions - 41-104°F (5-40°C)
- relative humidity max. 80%
Suitable for outdoor use no
1.6 Transport of The Unit
The Wireless Control System is designed to be used primarily in
conjunction with the Plymovent OS-3 control box.
The manufacturer cannot be held liable for any damage to the
unit due to shipping or mishandling. Always handle the unit and
the accompanying options and/or accessories, if any, with care.
2 PRODUCT DESCRIPTION
2.1 Operation
The Wireless Controller Receiver is designed to be connected to
a Plymovent control box. This unit is designed to draw its power
from the control box and provide a set of dry contacts by which
the control box can be triggered. These contacts are activated by
a properly wired and programmed transmitter at a distance of up
to 500 feet away. This transmitter must be used in conjunction
with a normally open (NO) switch, for example a pressure or
temperature switch, micro-switch or other such item.
