PMA Digital 280-1 - Configuration

5.2 Configuration
Dependent of instrument version and configuration, spare parameters are not dis
-
played.
Func
name value range description default
Fnc.1
function 1
0
0
no function
1
tare - function
2
sample & hold
3
O2 - measuring
Fnc.2
function 2
0
0
indicator
1
controller
C.Fnc
controller behavior (algorithm)
1
0
on/off controller e.g. signaller with one output
1
PID-controller (2-point and continuous)
C.Act
operating principle of the controller
0
0
inverse, e.g. heating
1
direct, e.g. cooling
rnG.L
-19999...99999
X0 (lower controlrange limit) 1
-100
rnG.H
-19999...99999
X100 (upper controlrange limit) 1
1200
1 rnG.L and rnG.H indicate the control range to which self-tuning refers.
InP
name value range description default
S.tYP
sensortype
1
0
thermocouple type L (-100...900°C), Fe-CuNi DIN
1
thermocouple type J (-100...1200°C), Fe-CuNi
2
thermocouple type K (-100...1350°C), NiCr-Ni
3
thermocouple type N (-100...1300°C), Nicrosil-Nisil
4
thermocouple type S (0...1760°C), PtRh-Pt10%
5
thermocouple type R (0...1760°C), PtRh-Pt13%
6
thermocouple type T (-200...400°C), Cu-CuNi
7
thermocouple type C (0...2315°C), W5%Re-W26%Re
8
thermocouple type D (0...2315°C), W3%Re-W25%Re
9
thermocouple type E (-100...1000°C), NiCr-CuNi
10 thermocouple type B (0/100...1820°C), PtRh-Pt6%
18
thermocouple Sonder (linearization necessary)
20
pt100 (-200.0 ... 100,0 °C)
21
pt100 (-200.0 ... 850,0 °C)
22
pt1000 (-200.0...8500.0 °C)
23
special 0...4500 Ohm (preset to KTY11-6)
24
special 0...450 Ohm (scaling necessary)
30
0...20mA / 4...20 mA (scaling necessary r page 36)
40
0...10V / 2...10 V (scaling necessary r page36)
41
special (-2,5...115 mV scaling necessary r page36)
42
special (-25...1150 mV scaling necessary r page 36)
Configuration level
24 Configuration Digital 280-1
