name value range description default
Y.1
controller output Y1
0
0
not active
1
active
Lim.1
Lim.2
Lim.3
message limit value 1/2/3
0
not active
1
active
Out. 1/2/3
FAi.1
message INP error
0
0
not active
1
active
fOut
forcing OUT1 (2) (only visible with BlueControl!)
0
0
no forcing
1
forcing via interface
Out.3
name value range description default
O.tYP
signaltype OUT3
0
0
relay / logic
1
0 ... 20 mA continuous
2
4 ... 20 mA continuous
3
0...10V continuous
4
2...10V continuous
5
transmitter supply
O.Act
circuit direction of output OUT3 (only visible with O.TYP=0 )
1
0
direct / open circuit principle
1
inverse / closed circuit priciple
Y.1
controller output Y1 (only visible with O.TYP=0)
0
0
not active
1
active
Lim.1
message limit value 1 (only visible with O.TYP=0)
1
0
not active
1
active
Lim.2
Lim.3
message limit value 2/3 (only visible with O.TYP=0)
0
0
not active
1
active
FAi.1
message INP-error (only visible with O.TYP=0)
1
0
not active
1
active
Out.0
-19999...
99999
scaling of analog output for 0% (0/4mA e.g. 0/2V, only visible
with O.TYP=1..5)
0
Out.1
-19999...
99999
scaling of analog output for 100% (20mA bzw. 10V, only
visible with O.TYP=1..5)
100
O.Src
signalsource for analog output OUT3 (only visible with
O.TYP=1..5)
1
0
not active
1
controller output y1 (continuous)
3
process value
4
effective set-point Weff
5
control deviation xw (process value - set-point )
Configuration level
26 Configuration Digital 280-1
