PMC Pm25LV010 - TIMING DIAGRAMS - INITIAL; RDID, WREN, WRDI Timing

17
Programmable Microelectronics Corp. Issue Date: February, 2004, Rev: 1.4
PMC Pm25LV512/010
TIMING DIAGRAMS
SCK
SI
SO
INSTRUCTION = 0000 0110b
HI-Z
CE#
WREN Timing
WRDI Timing
CE#
SCK
SI
SO
INSTRUCTION = 0000 0100b
HI-Z
nnnnnnN
01 8
31
38 39
46
47 54
HIGH IMPEDANCE
Manufacture ID1 Device ID
Manufacture ID2
SCK
CE#
SI
SO
INSTRUCTION
97
1010 1011b
3 Dummy Bytes
RDID Timing
