PMC Pm25LV010 - TIMING DIAGRAMS - DATA TRANSFER; FAST_READ, PAGE PROGRAM Timing

19
Programmable Microelectronics Corp. Issue Date: February, 2004, Rev: 1.4
PMC Pm25LV512/010
PAGE PROGRAM Timing
0 1 2 3 4 5 6 7 8 9 10 11 28 29 30 31 32 33 34
2075 2076 2077 2078 2079
076 532 21143023 22 21
1st BYTE DATA-IN
256th BYTE DATA-IN
3-BYTE ADDRESS
INSTRUCTION = 0000 0010b
HIGH IMPEDANCE
CE#
SCK
SI
SO
FAST READ Timing
0 1 2 3 4 5 6 7 8 9 10 11 28 29 30 31
...
23 22 21 3 2 1 0
3-BYTE ADDRESS
INSTRUCTION = 0000 1011b
HIGH IMPEDANCE
CE#
SCK
SI
SO
32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47
765
3
0
76543210
HIGH IMPEDANCE
CE#
SCK
SI
SO
4 1
76543210
2
DATA OUT 1 DATA OUT 2
DUMMY BYTE
