PNI CT36 - Technical Details and Specifications; Main Unit Description; Receiver Description

EN
10
TECHNICAL DETAILS / SPECIFICATIONS
- Main unit power supply: 2 AAA batteries
- Receiver power supply: 230VAC 50 / 60Hz
- Receiver unit command type: NO Relay (normally open) 10 Amps max not energized / dry contact
- Relay parameters: 250 V max, 10 Amps max (rezistiv), AC/DC curent
- Set point range temperature: 5 - 35
°
C ( 0.5
°
C step)
- Measurable ambient temperature: 0 - 50
°
C ( 0.1
°
C step)
- Temperature measurement unit: only
o
Celsius degrees
- Acceptable humidity: 85% no condensation
- Screen illumination: white light
- Temperature sensor: NTC 10K, 3950ohms at 25°C
- Sensor accuracy: ± 0.1 °C (0.5 °C step sensor calibration)
- Protection degree: IP30
- Housing: ABS with UL94-5 re retardant plastic standard
- WiFi connectivity: 802.11 b / g / n (2.4 GHz); WPA2 (TKIP and AES)
- RF frequency connectivity between units: 868 MHz
- Smartphone Compatibility: Minimum iOS 9 / minimum Android 4.2
MAIN UNIT DESCRIPTION
RECEIVER DESCRIPTION
Weekday
Clock
Set. Temperature
Heating Icon
Wireless signal
Room Temperature
Programable Period
PRG. Button
Modes Select
On/O Button Temperature and parameter settings
OWD Icon
On/O Button
Code pairing Button
Heating On Indicator ( LED 1)
Power Indicator ( LED 2)
