PNI DF780 - English

User manual 3 English
Technical specifications
Outdoor unit (camera)
Supply voltage 12 - 15V DC
Max. current (Amper) 200mA
Standby current 30mA
Camera sensor 1/4 CMOS, 2MP 1080P
Lens 3.6 mm
View angle 120°
Night vision 6 LEDs
Protection grade IP65
Relay
Non-energized relay, NC, COM, NO for
electromagnetic lock
Motion detection Yes
Audio recording Yes
Video recording Yes
Video resolution 1080P
Dimensions 125 x 56 x 21 mm
Indoor unit (monitor)
Supply voltage 12 - 15V DC
Max. current (Amper) 200mA
Standby current 30mA
Display size 7 inch
Display resolution 1024 x 600px
Recordings storage micro SD card slot (max. 128Gb)
Image memory up to 100 images
Ringtones 6 tones
Dimensions 207 x 144 x 23 mm
Main features
• Control of two doors.
• It supports the connection of 4 monitors, 2 external units and 2 CCTV
surveillance cameras.
