PNI IP60 - Technical Specifications - Camera and Network; Camera Feature Specifications; Network and Connectivity Details; LEDs and Power Supply Specs

15 User manual
English
Connect the second joint using
the 3 dedicated screws in the box
(one bigger and 2 smaller)
Connect the camera to the support
using the 4 dedicated screws in the
box.
Techical specifications
Camera
Sensor F23 CMOS
Sensor resolution 2MP
Registration resolution 1920 x 1080 / 1-30 fps
Lux
Color: 0.1Lux @(F1.2,AGC ON); 0 Lux with
IR, Black/White 0.01 Lux @ (F1.2,AGC ON),0
Lux with IR
Video compression H.264
Audio compression AMR/G.711A
Lens / Zoom 2.8-12mm / 5X Zoom Optic
Ethernet 10/100 Mbps RJ45
GSM network
4G GSM Nano SIM
Frequency 900/1800 MHz
IR LEDs 4 pcs. night vision up to 20 m
White LEDs 4 pcs. for additional night lighting
Motion detection Yes + Human detection
Card slot Micro SD, max. 128Gb
P2P connection Yes
App CamHi (Adroid/iOS) / HiP2P (Windows)
Supply voltage 12V / 2A
