Manual maneuver of the electrical keel system :
In case of an energy breakdown, you can manually activate the keel to put it in top or bottom
position.
To do so:
Remove the wooden panel situated on the port side of the central furniture, under the table,
in order to have access to the hydraulic system.
Grab the handle of the hand pump (fixed in the central furniture, in front of the jack.)
Put the handle on the manual hand pump, (see pict. below).
To lower the keel: Push the activation knob down strongly and turn it by a quarter to lock it in
position and then pump.
To lift the keel: Pull the activation knob up and lock it up by a quarter and then pump.
