16
10. Electricity
The standard electrical system of the Pogo 36 is composed of the following elements:
One engine battery, 60Ah, devoted strictly to start the engine, installed in the engine
compartment, in front of the engine and accessible by the companionway opening. The
circuit breakers are located on the starboard side of the engine compartment.
One 100Ah service battery as standard, also installed in the engine compartment (next to the
engine battery) with the circuit breakers on the starboard side of the engine compartment.
As an option, you may have one or two additional service batteries installed at the same
place.
Electrical panel:
A main electrical panel on the chart table console
Circuit breakers for the lifting keel pump and the windlass (options) on the longitudinal
bulkhead of the starboard aft cabin (See photo N°8).
The Electrical installation was designed for the equipment on board. It is recommended not to
connect additional devices on the existing installation.
Check regularly the condition of the battery fixations (notably the straps).
Warning, never work on the electrical installations when the power is on.
Do not modify the electrical scheme of the boat made by the shipyard. The installation, modifications
and the maintenance must be made by a professional marine electrician.
Do not change the circuit breakers fuse rating.
Do not install or modify any equipment with electrical current higher than that previously installed.
Do not leave the boat with the electrical current system on, except for protective systems for fire
protection or alarm systems.
The electrical wiring diagram is available at the end of this manual
